Century-Long Vinyl MIL SPEC Smooth Top Switchboard Matting
Tested to the requirements of MIL-DTL-15562G Type II


The Mat King Century-Long MIL SPEC Smooth Top Switchboard Matting conforms to the requirements of MIL-DTL-15562G Type II. It features a smooth top surface and a knurled back finish to provide a measure of skid resistance. It is made from an exclusive proprietary vinyl formula.

There are many industrial and commercial applications that take advantage of the characteristics unique to this specification, which include testing requirements for performance following exposure to sulfuric acid, oxygen bomb aging and ultraviolet light exposure.

Available in three colors: Black, Blue or Green


Tested to MIL-DTL-15562G
Type II Smooth Top

(1/8" thick)
Dielectric Test Voltage
30,000 VAC
Proof Tested Over Entire Surface at
15,000 VAC
Recommended Maximum Use Voltage
3,000 VAC
Fire Resistance
Mil Std 1623
Abrasion Resistance, Less than 20 mils lost
ASTM D-1242
Sulphuric Acid Aging, 70% of Tensile
Mil-DTL-15562G
Oxygen Bomb Aging, 80% of Tensile
Mil-DTL-15562G
Light Aging, 65% of Tensile
Mil-DTL-15562G


Sold in Full-Rolls Only
Product Number Item Description Detailed Description Price/LY  Price/LY
9928-401-3625 Century-Long Switchboard Matting-Vinyl MiL-Spec Smooth Top 1/8"x36"x25 yards Black Century-Long Switchboard Matting per MIL-DTL-15562G Type II Smooth Top, Recommended Maximum Use 3,000 VAC, Black, Knurled Back, 1/8"x36"x 25 yards 245# $/LY (rack#: 39-46-2036-981) $44.00 $1,100.00
9928-404-3625 Century-Long Switchboard Matting-Vinyl MiL-Spec Smooth Top 1/8"x36"x25 yards Blue Century-Long Switchboard Matting per MIL-DTL-15562G Type II Smooth Top, Recommended Maximum Use 3,000 VAC, Blue, Knurled Back, 1/8"x36"x 25 yards 245# $/LY (rack#: 39-46-2000-701) $44.00 $1,100.00
9928-408-3625 Century-Long Switchboard Matting-Vinyl MiL-Spec Smooth Top 1/8"x36"x25 yards Green Century-Long Switchboard Matting per MIL-DTL-15562G Type II Smooth Top, Recommended Maximum Use 3,000 VAC, Green, Knurled Back, 1/8"x36"x 25 yards 245# $/LY (rack#: 39-46-2000-801) $44.00 $1,100.00

Prices are exclusive of Freight. Provide "Ship To" city, state, and Zip Code with quantity of each type of matting required for custom quote via E-mail, Fax, phone or mail.



Technical Specifications
