Big D Shower Matting
Shower Room & Shower Stall Slip & Fall Prevention

      Big D Shower Matting is comprised of interlocking tiles with wide holes that provide free and easy draining for water, soap, shampoo and lotions where dependable sure footing is essential. Institutions and public facilities that want to minimize the likelihood of accident, injury and disease can use the Big D Matting System to do just that. Beveled safety edges can be supplied in contrasting colors for added safety.

Crafted from recycled plastic, Big D Shower Matting is an interlocking roll-up matting system designed for ground conditions where footing can be difficult or dangerous. It is available in a variety of patterns and colors, is simple to install, is free draining and easy to clean.
Big D Mat Roll
Barefoot Drain Tile System - was designed to prevent the growth of micro-organisms which cause skin disease such as athletes foot and tinea. The rubber and PVC material is impregnated with an anti-microbial additive. It can be used to create a healthier environment in sports locker rooms, shower facilities and swimming pool areas while, at the same time, providing a sure grip for wet feet.
Aqua Step Drain Tile Model
Big D Mat
Aqua Step Drain Tile Model
Colors: Black, Grey, Blue, White,Green, Yellow, Red
Color Choices
Temperature: Suitable for use in temperatures ranging from -86F (-30C) to +184F (+90C).
Material: Rubber and flexible PVC.
Packaging: Packed in boxes of 20 tiles with the box size being 20-3/8"(515 mm) long x 20-3/8"(515 mm) wide x 6"(150 mm) high. A full 20 ft. container hold approximately 14,600 tiles.
Color Choices



Dimensions: Tile: 20"x 10"x 9/16" (500 mm x 250 mm x 15 mm). Edge: 20"x 2-1/2"x 9/16" Corner Edge: 22"x 2-1/2"x 9/16". Dimensions are nominal.

Installation: For easy interlocking of tiles and edge ramps apply soapy water to male and female lugs and tap together with a hammer. For permanent fixture apply a small amount of PVC glue or cement to the lugs before interlocking. Assembly can be Plain, matching similar dimension to similar dimension; Parquet or Brick.

In Brick Style applications tiles at the opposite ends of alternating row will need to be cut in half and the cut away pat used on the opposite row end. Edge Ramps can not be attached to cut tiles unless lugs on the ramps are also cut away and PVC cement is used to attach the ramp.



Product Number Summary Description Detailed Description
Price/Tile
7517-101-2010 Drain Matting Big D with Large Holes Blk/1-999 Big D Interlocking Matting w/large holes; Color: BLACK; Size: 20"x 10"x 9/16"; 1#-8oz/tile; for 1-999 tiles (rack#: V-7517-101-2010)
$12.60
7517-102-2010 Drain Matting Big D with Large Holes Blue/1-999 Big D Interlocking Matting w/large holes; Color: BLUE; Size: 20"x 10"x 9/16"; 1#-8oz/tile; for 1-999 tiles (rack#: V-7517-102-2010)
$12.60
7517-103-2010 Drain Matting Big D with Large Holes White 1-999 Big D Interlocking Matting w/large holes; Color: WHITE; Size: 20"x 10"x 9/16"; 1#-8oz/tile; for 1-999 tiles (rack#: V-7517-103-2010)
$12.60
7517-104-2010 Drain Matting Big D with Large Holes Grey 1-999 Big D Interlocking Drain Matting w/large holes; Color: GREY; Size: 20"x 10"x 9/16"; 1#-8oz/tile; for 1-999 tiles (rack#: V-7517-104-2010)
$12.60
7517-105-2010 Drain Matting Big with Large Holes Red 1-999 Big D Interlocking Drain Matting w/large holes; Color: RED; Size: 20"x 10"x 9/16"; 1#-8oz/tile; for 1-999 tiles (rack#: V-7517-105-2010)
$12.60
7517-106-2010 Drain Matting Big D with Large Holes Green 1-999 Big D Interlocking Matting w/large holes; Color: GREEN; Size: 20"x 10"x 9/16"; 1#-8oz/tile; for 1-999 tiles (rack#: V-7517-106-2010)
$12.60
7517-107-2010 Drain Matting Big D with Large Holes Yellow 1-999 Big D Interlocking Matting w/large holes; Color: YELLOW; Size: 20"x 10"x 9/16"; 1#-8oz/tile; for 1-999 tiles (rack#: V-7517-107-2010)
$12.60

Prices are exclusive of freight which will be quoted on request. Deliveries to NY, CT and NJ will have appropriate Sales Tax added to final invoice.

Product Number Summary Description Detailed Description
Price/piece
7518-100-2002 Drain Matting Big D Beveled Edge Piece 1 - 999 Big D, Beveled Edge; Male/Female, Color: (Blue Black White Grey Red Green Yellow); Size: 20"x 2-1/2""x 9/16 -> 0"; 8oz/edge; Qty 1-999 (rack#: 7518-100-2002)
$11.53
7518-100-2202 Drain Matting Big D Bevel Edge and Corner Piece 1 - 999 Big D Beveled Corner;Male/Female,Color: Blue Black White Grey Red Green Yellow; Size: 20"x 2-1/2""x 9/16 -> 0"; 8oz/edge; Qty 1-1000. (rack#: 7518-100-2202)
$11.53

Prices are exclusive of freight which will be quoted on request. Deliveries to NY, CT and NJ will have appropriate Sales Tax added to final invoice.
