| Pad Selection Guidelines |
| Situation
Description |
Typical
Users |
Product
Suggestion |
Ptoduct
Number |
Description |
Price/each |
| Ground is fairly
stable and regular; machine weighs less than 25,000 lbs. |
Everyday use
such as cemeteries, residential estate yard
work, golf courses. |
Earthmoving Machine Ground Stabilizer
Pads
- Regular |
3780-100-2424 |
Stabilizer/Outrigger
Pad; 24" x 24" x 5-ply with hand cutouts; 12#/pad; $/mat
(rack#: 2424HDS) |
$275.56 |
| Ground is fairly
stable and regular; machine weighs less than 25,000 lbs. however
the machine's outriggers have somewhat larger footprint. |
Everyday use
such as cemeteries, residential estate yard
work, golf courses. |
Earthmoving Machine Ground Stabilizer
Pads
- Regular |
3780-100-3232 |
Stabilizer/Outrigger
Pad; 32" x 32" x 5-ply with hand cutouts; 30#/pad; $/mat
(rack#: 3232HDS) |
$400.00 |
| Rough field
conditions; machine weighs more than 25,000 lbs. |
Utility work. |
Earthmoving Machine Ground Stabilizer
Pads
- Extreme Use |
3780-200-2424 |
Stabilizer/Outrigger
Pad; 24" x 24" x 7-ply with rope handles; 20#/pad; $/mat
(rack#: 2424ORG) |
$351.11 |
| Highly demanding
field conditions; tandem machine weighs from 35,000 to 70,000 lbs. |
Utility work. |
Earthmoving Machine Ground Stabilizer
Pads
- Extreme Use |
3780-200-3232 |
Stabilizer/Outrigger
Pad; 32" x 32" x 7-ply with rope handles; 38#/pad; $/mat
(rack#: 3232ORG) |
$551.11 |
| General
Guidelines: |
| 1.
Use one Pad per stabilizer or outrigger. |
| 2.
Do not allow edges of a pad to bow up or flex more than 1/2".
If that condition exists, stop use right away and use cribbing blocks
to correct it. |
| 3.
It is best that the Ground Stabilizer Pad be no more than 1/3 larger
than the diameter or footprint of the machine's stabilizer pad. |
| 4.
We use the terms Stabilizer and Outrigger interchangably because
in some industries one or the other terms is uses to refer to this
part of the machine. |
